Adhesive E10
Adhesive E10
Product Briefing
Adhesive E10 is a tooling specific product. This product is a bonding mortar made by accurately mixing various cement-based mortar additives such as high-grade Portland cement, selected graded sand, and professionally formulated water retention factors. It ensures that the cement components are fully hardened to improve various properties, and has the advantages of simple operation and easy construction, becoming a new type of tile laying product that replaces traditional cement mortar systems.
Product Features
High bonding strength
Convenient construction
Green and environmentally friendly
Product specifications
Product specification: 40kg/bag
Scope of application
Suitable for wall and ground stable base, such as concrete, cement mortar, cement-based waterproof mortar and other base tiling.
Execution standards
GB/t25181-2019dta-I type
Construction method
Base treatment
The base layer should be solid, clean, free from shaking, oil stains, wax stains, concrete curing agents, and other loose materials. Before construction, it is necessary to wet the base layer to a dry outside and wet inside state in areas with high water absorption or in high-temperature and dry environments. After the completion of the new concrete surface construction, it should be cured for 28 days before tiling. The old concrete and plaster surfaces can be cleaned with a cleaning agent, rinsed with a high-pressure faucet, and dried for 24 hours before tiling.
Preparation of adhesive slurry
Mix the adhesive slurry by adding an appropriate amount of water to the mixing bucket and slowly adding the powder while stirring. The mixing ratio is 40kg of powder and 9-10L of water (subject to convenient construction). Stir evenly with an electric mixer until there are no lumps, let it sit for 5-10 minutes, and mix thoroughly again before use. It is best to complete the construction within 2 hours.
Ceramic tile pasting
Use a toothed scraper to apply tile adhesive to the base layer, evenly distribute it, and comb it into tooth shaped strips. Apply about 1 square meter each time, and then knead and press the tiles on top during the drying time. The depth of the scraper teeth should consider the flatness of the working surface and the unevenness of the back of the ceramic tiles.
Precautions
The optimal construction temperature should be between 5-35 ℃.
This product does not have waterproof effect. Please use waterproof products if needed.
The base surface must be flat and sturdy.
Ensure the fullness during construction and maintain complete contact between the contact surfaces.
The mortar must be protected before it solidifies to avoid outdoor construction in rainy weather, so as not to affect its quality.
This product contains cement ingredients, and attention should be paid to protecting the eyes. In case of contact, it can be washed with plenty of water.
Reference amount
(Approximate value, depending on the flatness of the base surface)
| Specification of toothed scraper | usage |
| 6mm*6mm | 3kg/㎡ |
| 10mm*10mm | 5kg/㎡ |
| 12mm*12mm | 8kg/㎡ |
Transportation and storage
Avoid rain and sun exposure during transportation. Store in a cool and dry warehouse to prevent moisture and strictly prohibit contact with water.
Storage period: 6 months.
